STL File-The Reveal 2.0-Personal Use Only

***Please Read Description***

*Please do not open these files on your phone as you only have one download*

It's a nuclear reactor! It's a vacuum cleaner filter! It's a turbine! No, it's REVEAL 2.0! Where Lord of the Rings and Star Wars meets 3D printing, this second version of The Reveal is a fun take on the original design. The 2.0 has same mechanisms that allow you to brighten or dim your lamp and fidget to your hearts content.

This lamp combines 3d printing and metal hardware for strength and stability. The movement is contagious, perfect for fidgeting leaving you mesmerized by the casting of light and shadow.

The tallest part is 210 mm tall. Take into consideration your printers Z height.

The longest parts are the fins. They are 282 mm long. Minimum size of build plate: 210 mm X 210 mm. They would be printed diagonally.

Every other part could be printed on a 177 mm X 177 mm build plate.

The 3mm Socket you get in the files was made by SoulRider911. Go check out his account on Printables and YouTube!

Hardware List   ***NOT INCLUDED***

28 - 1/8 in. (3.175 mm) Dowels @ 7/16 in. (11.11mm Long)

(You can use wood or plastic, whatever you prefer)

8 - M3 X .5 mm thread - Hex Nuts

4 - M3 - .5 mm thread - Threaded Rod @ 8 11/16 in. (220.7 mm Long)

***If you are printing the shorter version:***

4 - M3 - .5 mm thread - Threaded Rod @ 7.399 in. (187.959 mm Long)

***ALWAYS DOUBLE CHECK YOUR LENGTHS BEFORE CUTTING EVEN PUT RODS IN PLACE BEFORE CUTTING TO VERIFY THE PROPER LENGTH***

4 - 1 in. (25.4 mm) #8 Pan Socket Head Screw - cut to 7/8 in (22.23 mm)

3 - 1/2 in. (12.7 mm) #8 Pan Socket Screw

Included

• All STL files needed to print the lamp.
• A PDF instruction manual with parts list, hardware list and some print instructions for the tricky bits.
• A tutorial video.
• *Please do not open these files on your phone as you only have one download*

Dimensions:
Height: 14.375 inches
Fins open width: 6.5 inches
Fins closed width: 5.5 inches

These files are not for resale.

The Reveal 2.0 - Personal Use Only © 2024 by Charlie Severson is licensed under CC BY-NC 4.0
